OpenFOAM tricks & tips: Debugging and VSCode intellisense

Motivation

OpenFOAM is compiled for maximal performance (default)

Floating point error (e.g. division by zero):

             Foam::error::printStack(Foam::Ostream&) at ??:?
             Foam::sigFpe::sigHandler(int) at ??:?
             ? in "/lib/x86_64-linux-gnu/libc.so.6"


OpenFOAM compiled with debug modus (poor performance):

             Program received signal SIGFPE, Arithmetic exception.
             0x00007ffff6668e5f in Foam::divide <double> (res=..., f1=...,
             at  /home/bram/openfoam4_debug/src/OpenFOAM/lnInclude/FieldFunctions.C:631/
            631 BINARY_TYPE_OPERATOR_FS(Type, Type, scalar, /, divide)


Notice: specific error info, file location, # line, etc.

Debugging in OpenFOAM

• Recompile OpenFOAM with debug modus
• Install GDB, the GNU debugger
• An OpenFOAM extension is available: GDBOF

Warning: Live session incoming!

GDB is really useful when developing OpenFOAM applications, not only for debugging but also as sandbox.

References

• Chalmer's OpenFOAM course
• GDBOF: A debugging tool for OpenFOAM
• GDB and OpenFOAM - a quick summary
• Stack overflow

VSCode

• Microsoft
• Free, Open Source (Windows, Linux, IOS)
• Like Atom, but lightweight and more active community

VSCode

I don't program in OpenFOAM, why is this useful?

• Easy and fast navigation to the implementation of solvers, boundary conditions, etc.
• Great git diff tool
• ...
